Electrical Specifications

Amperage : 20 A

Current Limiting : Full Rated Current

Dielectric Voltage : Withstands 2000V per UL498

Grounding : Self grounding

Pole : 1

Screw Terminal Torque : 14-18 in-lbs

Temperature Rise : Max 30C after 250 cycles OL at 200 percent rated current

Voltage : 125 VAC

Wire : 2

Mechanical Specifications

Product ID : Ratings are permanently marked on device

Terminal Accom. : 14-10 AWG

Terminal ID : Brass-Hot, Green-Ground, Silver-Neutral

Termination : Side Wire

Material Specifications

Clamp Nuts : Thermoplastic Nylon

Color : Black

Face Material : Thermoplastic Nylon

Ground Clips : Brass-Plated

Grounding Screw : Brass 8-32

Line Contacts : Brass Triple-Wipe .031 Thick

Environmental Specifications

Flammability : Rated V-2 per UL 94

Standards and Certifications

NOM : 057

UL 498 : File E13399

Warranty : 10-Year Limited

Product Features

Color : Black

NEMA : 5-20R
