Standards and Certifications

Listings : UL Listed and CSA certified (excludes PS200-70), UL 773 Enclosure Rating, meets ASHRAE Standard 90.1 requirements

Title 24 Compliant : Yes

Warranty

Warranty : 5-Year Limited

Electrical Specifications

Frequency : 50/60Hz

Neutral Wire Connection : Required

Power Consumption : 230V - 2.5W (PS200); 277V - 3.0W (PS200)

Voltage : 120 VAC

Performance Specifications

Coverage (Sq.Ft.) : 4000.0

Pattern : 200°

Product Features

Adjustment : Manual

Application : Parking areas, storage facilities, warehouses, loading docks, marinas, garages, walkways, campus grounds, meat lockers, walk-in refrigerators/freezers, and outbuildings

Color : White

Grade : Commercial

Load Rating : 1000W 500VA

Pattern Degrees : 200

Photo Cell : Ambient Override ON

Product Line : PS200

Protection : Surge Protected

Sensor Technology : Passive Infrared (PIR)

Sensor Type : Motion / Occupancy

Standards and Certifications : UL/CSA

Time Adjustment : 20s-15m

Time Delay : 20s-15m

Type

Product Type : Outdoor Motion Sensor

Mechanical Specifications

Neutral Wire Connection : Required

Environmental Specifications

Operating Temperature : -14° to 130°F (-10° to 55°C)

Storage Temperature Range : 0° to 131°F (-17° to 55°C)
