Support Grip, 0.75-1.00"
L9553-100
Support, Universal Eye Closed Mesh Support Grip, 0.75-1.00", 304 Stainless Steel- Breakload is 1,020 LB
- Leviton wire mesh grips are built tough to provide the strength, reliability, and gripping force required for today’s demanding wire mesh applications
- Support grips distribute the weight of the vertical or sloping runs of electrical and fiber optic cable, metal rods, tubing or hose over the entire length of the grip so the cable is not damaged
- Use of support grips avoids stress on cable connections and provides needed support for vertically hung cables
Product Information
Material Specifications
Mesh Material : 304 SS
Product Features
Device Type : Support Grip
Mechanical Specifications
Approx. Break Strength : 1020 lbs (460 kg)
Bale Length : 18 in (457 mm)
Cable Range : 0.75 - 1.00 in (19 - 25 mm)
Duty : Standard
Eye Type : Locking Bale
Mesh Length : 13 in (330 mm)
Mesh Style : Closed
Standards and Certifications : UL
Weave : Single Weave
Workload Safety Factor (lbs) : 102 lbs (46 kg)
Warranty
Warranty : 1-Year Limited
